Square Hole Perforated Sheets
Materials:
We manufacture square hole perforated sheets in a wide selection of materials, ensuring flexibility across different applications and preferences. Options include robust Mild Steel for general use, corrosion-resistant Stainless Steel for long-lasting performance, and lightweight Aluminum for projects requiring ease of handling. For specialized requirements, we also provide sheets in Brass and Copper, which offer distinct visual appeal along with reliable functionality. Galvanized Steel and customized alloys further expand the choices available, giving clients the freedom to select materials best suited to their specifications.
Hole Pattern:
Square hole perforated sheets are manufactured in three main arrangements: straight, staggered, and diagonal. Each pattern has its own characteristics and is chosen based on the balance between strength, open area, and design requirements.
The straight pattern is the most widely preferred, delivering neat alignment, uniform strength, and a professional appearance. It offers excellent load-bearing capacity and long-term durability, making it ideal for projects where precision, orderliness, and reliability are essential. Its clean grid design ensures a consistent look while maintaining structural integrity across different material options.
The straight pattern remains the best choice for unmatched reliability, strength, and overall performance.
Perforated Sheet Specification:
| Square Hole | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hole Size (mm) | Pitch (mm) | Open Rate | Sheet Thickness | ||||||||||||
| 90° | 0.50 mm | 0.60 mm | 2.50 mm | 1 mm | 1.20 mm | 1.50 mm | 2 mm | 3 mm | 4 mm | 5 mm | 6 mm | ||||
| 5 | 8 | 39.1 | * | * | * | * | * | * | * | * | * | * | * | ||
| 6 | 9 | 44.4 | * | * | * | * | * | * | * | * | * | * | * | ||
| 8 | 11 | 52.9 | * | * | * | * | * | * | * | * | * | * | * | ||
| 8 | 12 | 44.4 | * | * | * | * | * | * | * | * | * | * | * | ||
| 10 | 14 | 51.0 | * | * | * | * | * | * | * | * | * | * | * | ||
| 12 | 16 | 56.3 | * | * | * | * | * | * | * | * | * | * | * | ||
*
Marked are readily available in 3x8ft & 4x8ft Sheet Size, contact to know availability for other sizes in sheets and holes.
